86400-8006-805
| Technical specification sheet | |||
| | Product name | ||
| IdeaHub ES2-G | IdeaHub ES2 Pro-G | IdeaHub ES2 Pro NR-G | |
| 65": IHE2-65SU-G | 65": IHE2-65PU-G | 65": IHE2-65PM-G | |
| 75": IHE2-75SU-G | 75": IHE2-75PU-G | 86": IHE2-86PM-G | |
| 86": IHE2-86SU-G | 86": IHE2-86PU-G | | |
| Product dimensions (L X W X H) | |||
| 65":1484.5mm X 91.6mm X 947.5mm | |||
| 75":1705.7mm X 91.8mm X 1071.9mm | |||
| 86":1953.0mm X 91.8mm X 1212.0mm | |||
| Package dimensions (L x W x H) | |||
| 65": 1650mm X 220mm X 1050mm | |||
| 75": 1900mm X 220mm X 1170mm | |||
| 86": 2090mm X 250mm X 1300mm | |||
| Weight (net/gross weight - including packing case) | |||
| 65 ": 35.5 kg / 43.0 kg | |||
| 75": 47.0kg/ 57.0kg | |||
| 86": 62.0kg/ 73.5kg | |||
| Components | |||
| Complete machine | stylus | Matching cable | |
| 1 set | 2 pieces | 1 power cord | |
| Floor stand | Wall brackets | Smart screen projector | |
| Optional (65", 75", 86" universal) | Optional (65", 75 ", 86" general) | Optional (Type-C/Type-A interface) | |
| OPS pluggable computer | |||
| Optional | | | |
| Screen | | | |
| Resolution | Type of backlight | Bonding process | |
| 4K | D-LED | Zero fit | |
| Writing | |||
| Writing delay | Touch height | Intelligent writing recognition | |
| 16ms | ≤2mm | Support Chinese and English, 11 kinds of pattern recognition | |
| Video Camera | |||
| Resolution | Sharpness | Lens privacy cover | |
| 4K | 1800 line | Support | |
| Horizontal perspective | TV distortion | | |
| 80° | <2% | | |
| Speakers | |||
| Frequency domain | Number of speaker units | Total power | |
| 100Hz-20kHz | 4 | 40w | |
| Microphone | |||
| Pickup Angle | Picking distance | Frequency domain | |
| 180° | 12m | 80Hz-20kHz | |
| Pickup enhancement | | | |
| Sound source location, echo cancellation, automatic gain control | | | |
| Meetings | |||
| IdeaHub ES2-G | IdeaHub ES2 Pro-G/ES2 Pro NR-G | ||
| Adaptation Session: | Adaptation meeting: | ||
| Walk-in conference (License required), Huawei Cloud Conference SmartRooms, Huawei Cloud WeLink | Walk-in conference, Huawei Cloud Conference SmartRooms, Huawei Cloud WeLink | ||
| Conference effect: | Meeting effects: | ||
| Settled conference: 1080P30fps video +1080P30fps/4K8fps material sharing, with the License can support 720P60fps/1080P60fps video | Settled conference: 1080P30fps video +1080P30fps/4K8fps material sharing, with different licenses can support: 720P60fps/1080P60fps video; 4K30fps video + 4K30fps material sharing | ||
| Communication protocol | |||
| Multimedia framework protocol: ITU-TH.323, IETFSIP | |||
| AI Features | |||
| Smart framing (Auto-Framing) | Smart Director (speaker tracking) | Smart soundscreen | |
| Support | Support | Support | |
| DNN de-reverb | | | |
| Support | | | |
| System | |||
| CPU | RAM | Flash | |
| 8-core | 12GB | 64GB | |
| Operating system | Security | Language | |
| HarmonyOS, Windows(OPS optional) | Embedded encryption chip, support H.235, STARTTLS, TLS and SRTP encryption, secure boot, TEE (Trusted Execution environment) | Simplified Chinese, English, French, Japanese, Arabic, Spanish, Russian, Portuguese, Italian | |
| Wireless connection | |||
| IdeaHub ES2 | IdeaHub ES2 Pro | IdeaHub ES2 Pro NR | |
| Wi-fi 6, NFC | Wi-fi 6, NFC | Unsupported | |
| Interface | |||
| Front interface | Side port | ||
| 2 x USB 3.0 (USB Mic/Speaker/Camera supported) | 1 x HDMI IN (4K support) | 1x 3.5mm LINE IN | 1x RJ45 ( 10/100/1000M LAN ) |
| 1 x Type-C | 1 x HDMI OUT (4K supported) | 1x 3.5mm LINE OUT | 1 x HD-AI |
| | 1 x USB 3.0 (USB Mic/Speaker/Camera supported) | | |
| | 1 x Touch | | |
