Technical Parameters

Model Number

Camera 200-G 1080P

Camera 200-G 4K

Camera 200 Pro-G

Lens

Image Sensor

8.51 megapixel 1/2.3-inch CMOS image sensor

Video Output Pixels

1080p50/60, 1080P25-30, 720p50/60, 720P25-30

4K25/30, 1080p50/60, 1080P25-30, 720p50/60, 720P25-30

4K50/60, 4K25/30, 1080p50/60 , 1080P25-30, 720p50/60, 720P25-30

Lens Zoom

12x optical zoom

Aperture

F1.8 to F3.56 ± 5%

Focus Distance

3.85 to 43.06mm ± 5%

Maximum Horizontal/Vertical Viewing Angle

80.4°/ 50

Translation/Pitch Speed

Translation: 1.7°/s to 80°/s, pitch: 0.7°/s to 28°/s

Minimum Illumination

3lux (50IRE, F1.8)

Shutter Speed

1/25 to 1/10,000 second

Default Bit Number

255

Image Mode

Image mode

Standard, Natural, vivid, landscape, Conference

Auto Adjust

Automatic White Balance

Auto/Manual/-- Key White Balance/Specify color temperature

Auto Exposure

Auto/manual/aperture priority/shutter priority/brightness priority

Autofocus

Auto/Manual/- key focus

Featured Features

Digital Wide Dynamic

Support image digital wide dynamic WDR function

Support Inversion

Support camera inversion scenes

Remote Support

Support HD terminal infrared remote control through the camera to control HD terminal

Software Upgrade

Support localUSB interface software upgrade

Power Supply and Power

Input Voltage Range

100V-240VAC 50Hz/60Hz

Output Voltage

12VDC

Peak Power Consumption

<12W

<12W

<15W

Physical Characteristics

Ambient Temperature

0℃ and 40℃

dimension

(L × W × H)

Machine size: 249mm × 139mm × 155mmPackage Size: 425mm × 285mm × 320mm

Net Weight of Product

1.85 Kg

1.85 Kg

1.95 Kg

Gross Weight of Product

4.7 Kg

4.7 Kg

4.8 Kg

Interface

Video Output

1×HDMI port

1×USB Port

1×HDMI port

1×USB Port

1×HDMI port

1×USB Port 1×HT-TX port

Other Ports

2×RS232 serial port

2×RS232 serial port

2×RS232 serial port
