Height

4U

GPU

Supports 8 full height, full length, dual width PCIe interface GPU cards such as MLU370-X8 and RG800, and up to 5 PCIe 4.0 x 16 slots

Processor

2 HYGON 7300 series CPUs, TDP 225W

Memory

Supports 32 DDR4 RDIMM/LRDIMM memories with a memory bandwidth of 3200 MT/s

Storage

Supports 12 2.5-inch SSDs and supports hot swapping

PCIe Slot

Supports up to 13 standard PCIe 4.0 slots and 1 OCP 3.0 network slot

RAID Support

Optional support for RAID 0/1/10/5/50/6/60, and support for Cache supercapacitor protection

Front end I/O

1 USB 3.0 port, 1 USB 2.0 port, 1 VGA port

Rear I/O

2 USB 3.0 ports, 1 VGA port, 1 BMC management port, 1 system serial port

Administration

Plug in DC-SCM board outside the chassis, supporting self-developed ZX1000 series BMC chips

System Cooling

12 hot swappable fans, supporting N+1 redundancy

Power Supply

Supports 4 CRPS platinum power supplies and N+N redundancy

Size

447mm(W) × 174.5mm(H) × 850mm(D)
