Specifications

Microwave Type

IP microwave over Native Ethernet/PWE3 Ethernet
Microwave carrying 10GE eCPRI

Frequency Band

71GHz–76GHz /81GHz–86 GHz

Channel Spacing

62.5 MHz, 125 MHz, 250 MHz, 500 MHz, 750 MHz, 1000 MHz, 1500 MHz, 2000 MHz

Modulation Scheme

BPSK, QPSK, 8PSK, 16QAM, 32QAM, 64QAM, 128QAM, 256QAM, 512QAM, 1024QAM

Port Type

Auxiliary port

USB port, RSSI port, NMS port, XPIC port

Service port

1*COMBO+1*10GE (o)+1*P&E

Capacity

Maximum air-interface bandwidth: 10 Gbps
Maximum air-interface throughput: 10 Gbps
Switching capacity: 60 Gbps

RF Configuration

Supports 1+0, 2+0, 1+1 HSB, XPIC, and multi-direction configuration.

Service Type

Native Ethernet services: E-Line, E-LAN
PW-based Ethernet services: E-Line, E-LAN (VPLS)

NMS

NCE, Web LCT, SNMP, built-in web-based NMS

Ethernet OAM

IEEE 802.1ag, IEEE 802.3ah, ITU-T Y.1731

Key Features

AMAC, ATPC, ERPS, PLA, QoS/HQoS, Bandwidth Notification,TWAMP/TWAMP Light, Anti-theft, Super Dual Band, L3VPN, eCPRI

Clock Features

Supported clock sources: microwave link clock, synchronous Ethernet clock
IEEE 1588v2 time synchronization
ITU-T G.8275.1 time synchronization

Power Supply Mode

DC Power Supply and P&E Power Supply (Mutual Backup)

Antenna

Dish antenna: 0.2m, 0.3m, 0.6mPanel
antenna: 0.3m x 0.3 mWide-beam
antenna: 0.3m x 0.077m IBT antenna: 0.6m

Power Consumption

Typical Power Consumption: 49 W
Maximum Value of Power Consumption: 79 W

Dimensions (H x W x D)

320 mm x 265 mm x 73.5 mm

Weight

5 kg

Environment

Temperature:–33ºC to +55ºC
Humidity: 5% to 100%
Protection class: IP66
