Protocols and standards

Multimedia Framework Protocols

ITU-T H.323, IETF SIP

Video codec protocol

H.264 HP, H.264 BP

Audio codec protocol

Opus, iLBC, AAC-LD, AAC-LC, G.729A/AB, G.722.1C, G.722, G.711A/U

Network Transport Protocol

IPV4, IPV6, TCP/IP, RTP, RTCP, HTTP/HTTPS, SNMP, RTMP, RTMPS

Other protocols and standards

SRTP, TLS, IPSAN, NAS (NFS)

System performance

Maximum number of concurrent recordings/live broadcasts

10 channel 1080p60/20 channel 1080p30/40 channel 720p30 video stream

Max concurrent on-demand/live stream views

2250 lines @192Kbps / 1500 lines @256Kbps/ 750 lines @512Kbps / 500 lines @768Kbps / 350 lines @1Mbps / 170 lines @2Mbps

Video recording and broadcasting format

1080p60, 1080p30, 720p30, 4CIF

Maximum number of pure audio recordings

300 channels

Storage capacity

Standard Edition: 2.4T, Max 3,200 hours @512Kbps recording

Premium Edition: 7.2T, Max 26,000 hours @512Kbps recording

Other parameters

Language

Simplified Chinese, English

Physical characteristics

Network interface

Electrical port: GE, RJ45 Serial port: RJ45

Device Size

H 86.1 mm x W 447mm x D 790 mm (2U)

Weight

Net weight: 23kg Gross weight: 28kg

Power supply parameters

Ac: 100V ~ 240V Power consumption: <900W

Operating temperature

5°C to 45°C (41°F to 113°F)

Operating humidity

8% to 90% (RH, non-condensing)

MTBF

> 100,000 hours

MTTR

<1 hour

Environmental suitability

Perfect environment, safety, EMC and reliability design, intelligent thermal protection

The protection automatically adjusts the internal temperature to ensure smooth operation
